SPECIFICATIONS

name: HANMA
Wheelbase: Screws
Brand Name: RADIOMASTER
Model Number: POCKET
Use: Vehicles & Remote Control Toys
Material: Plastic
Tool Supplies: Battery
For Vehicle Type: Airplanes
RC Parts & Accs: Radio Systems
Origin: Mainland China
Technical parameters: KV1100
Four-wheel Drive Attributes: Assemblage
Is Electric: No battery
Upgrade Parts/Accessories: Adapter
Remote Control Peripherals/Devices: Remote Controller
Recommend Age: 14+y

Notes:
 CC2500 (standard) Version supports all CC2500 protocols
 ELRS (standard) is pre-installed witn ExpressLRS ISM FW (Max power is hardware dependnant)

Features
Available in ExpressLRS and MPM CC2500 versions
Preinstalled with EdgeTX firmware
18650 Batteries, all the power you need for hours of fun
Portable and lightweight design with removable stick ends and foldable antenna
Features hall effect gimbals as standard for smooth cantering & precise response
Built-in LED lights helps visualize your switch inputs
Backlit LCD Screen offering a perfect balance of size and functionality
Trim buttons for easy channel trimming
External Module Bay compatible with RadioMaster Nano-size modules and TBS Nano Crossfire/Nano Tracer
2 Stylish Colors of Charcoal & Transparent version and optional case colors in Blue, Pink, Green, Orange to suit your style

Specifications
Item: Pocket Radio
Physical dimensions: 156.6*65.1*125.3mm (Folded size) /156.6*73.1*154.8mm (Unfold size）
Weight: 288 grams
Operating frequency: 2.400GHz-2.480GHz
Internal RF Options: CC2500 multi-protocol / ELRS 2.4GHz
Supported protocols: Module dependent
RF power: CC2500:100mW Max (20dBm) / ELRS FCC: 250mW Max (24dBm) / ELRS EU-LBT: 100mW Max (20dBm)
Operational voltage: 6.6-8.4v DC
Control distance: > 2km @ 20dBm
Operating system: EdgeTX
Control channels: Maximum 16 (Receiver dependent)
Display: 128*64 Monochrome LCD
Battery: 2pcs 18650 batteries (Not included)
Charging: Built in USB-C QC3 Charging
Upgradable Firmware: Via USB or the included SD card
Gimbal: Hall-effect
Module bay: Nano size (Compatible with RadioMaster Nano-size modules, TBS Nano Crossfire / Nano Tracer )

Package Including
1 * Pocket Radio
1 * Custom Carry Pouch
1 * USB-C Cable
1 * Screen Protector
1 * Sticker
4 * Low Tension Springs
1 * Manual
